THR Fountain solenoid valves are widely used in fountain construction, you can see its parameters and photos below, if you have any questions free let us know please.
| Model | GG15 | Model | GG25 |
| Working Medium | Water | Working Medium | Water |
| Material | Stainless steel | Material | Stainless steel |
| Action Method | Straight movement | Action Method | Straight movement |
| Type | Normally closed | Type | Normally closed |
| Port Size | G1/2" | Port Size | G" |
| Working Temperature | 0-60℃ | Working Temperature | 0-60℃ |
| Pressure range | 0-0.4Mpa | Pressure range | 0-0.4Mpa |
| Voltage | DC24V, AC110V, AC220V, AC380V | Voltage | DC24V, AC110V, AC220V, AC380V |
| Protect Grade | IP67 | Protect Grade | IP67 |
| Model | GG40 | Model | GG50 |
| Working Medium | Water | Working Medium | Water |
| Material | Stainless steel | Material | Stainless steel |
| Action Method | Straight movement | Action Method | Straight movement |
| Type | Normally closed | Type | Normally closed |
| Port Size | G1 1/2" | Port Size | G2" |
| Working Temperature | 0-60℃ | Working Temperature | 0-60℃ |
| Pressure range | 0-0.4Mpa | Pressure range | 0-0.4Mpa |
Voltage | DC24V, AC110V, AC220V, AC380V | Voltage | DC24V, AC110V, AC220V, AC380V |
| Protect Grade | IP67 | Protect Grade | IP67 |
Let me know your thoughts.
